20ft Foldable Expandable Prefabricated Container House Folding House Movable Prefab Home

Item

Details

External Dimensions (mm)

5800 L * 2500 W * 2380 H MM

Folded Dimensions (mm)

5800 * 2480 * 570

Total Mass (kg)

1000 - 1300 (including doors, windows and simple indoor electrical switches and sockets. 8 sets can be accommodated in 1 * 40HQ)

Main Frame - Top Main Beam

Rectangular square tube 60 × 80 × 1.3 mm

Main Frame - Top Bearing Bottom

Rectangular square tube 40 × 1.3 mm

Interior Ceiling

Color - steel facing v930 * 0.25 mm

Insulated Glass Wool

Glass wool roll 50 mm (unit weight 16 kg)

External Roof Panel

Galvanized sheet 0.5 mm

Overall Frame Protective Coating

Electrostatic spraying / high - gloss

Lifting Head

155*110 * (6 mm)

Bottom Frame - Bottom Main Beam

Rectangular square tube 60 × 140 × 1.3 mm

Bottom Frame - Bottom Bearing

Rectangular square tube 40 × 1.3 mm

Bottom Frame - Front and Rear Main Beams

Rectangular square tube 60 × 80 × 1.3 mm

Upright - Side Wall Frame

Rectangular square tube 40 × 60 × 1.3 mm

Galvanized Belt Buckle Groove

50 mm

Folding Hinge

Galvanized hinge 13 mm

Floor

Fire - proof glass - magnesium floor 18 mm

High - end Steel Door

High - quality safety door (warm white) 970 mm * 1970 mm

Anti - theft Window

930*1120, plastic - steel anti - theft integrated window, glass thickness 4mm (warm white) 2PCs

Simple Power Distribution

Electrical wiring is installed strictly in accordance with explosion - proof specifications. All electrical products shall comply with ce certification. Connect the circuit according to the electrical engineering specification. Indoor: coil in4² national standard flexible copper wire, 20 Acircuit circuit breakers 1, socket input wire 2.5², single three - hole socket 1pc, single five - hole sockets 3, 2 lights

Wall Panel

50 - mm composite panel 0.23 mm + basalt rock wool (unit weight 50 kg) + 0.23 mm

Optional Accessories

Furniture, sanitary facilities, kitchens, air conditioners, accommodation appliances, offices, dormitories, toilets, bathrooms, shower rooms, steel roofs, assembled panels, decorative materials, etc.

Load - bearing / Horizontal - Roof Load - bearing Capacity

≥ 50 kg/m²

Load - bearing / Horizontal - Aisle Load - bearing Capacity

≥ 200 kg/m²

Load - bearing / Horizontal - Floor Load - bearing

≥ 150 kg/m²

Load - bearing / Horizontal - Wall Side Pressure

≥ 80 kg/m²

Load - bearing / Horizontal - Wall Deformation Coefficient

300 kg/m²

Fire Rating

Class A

Earthquake Rating

Level 10

Wind Resistance Rating

Level 10

Customization Note

All the above specifications can be customized according to requirements
